A4BQ2501 Mersen Fuses
Part#:A4BQ2501
Manufacturer:Mersen
Category:Fuses
Alt. Part#:782001296087
Product Lifecycle:Active
Get a quick Quote!
A4BQ2501 Mersen - Fuse A4BQ - Class L - Time-Delay 600VAC 500VDC 2501A Blade Amp-Trap 2000®
About the manufacturer: Mersen is one of the manufacturers that offers Fuses that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.
Check out the A4BQ2501 Mersen price in the box on the right side or send a quick quote.
Product Details
- Current Rating 2501 A
- Terminal Type Blade
- Material GMG
- Type Low Voltage UL/CSA Fuses
- Weight 7750.315 g
- Voltage 600 VAC / 500 VDC
- Approvals A4BQ (100-6000) *UL listed to standard 248-10 File E2137 *DC listed to UL standard 248 (100-2000A) *CSA certified to standard C22.2 No. 248.10 (601-6000A) A4BQ (100-6000) - TA *UL listed
- UL Certification YES
- Trip Class Time Delay
- Fuse Class Class L
- Sell Pack Weight 20.27 lb
- Sell Pack Height 5.62 in
- Sell Pack Width 5.25 in
- Sell Pack Quantity 1 Each
- Sell Pack Length 11.75 in
- Product Weight 19.3 lb
- Product Length 10.75 in
- Body/Insulating Material GMG
- Product Diameter 5 in
- Connection/Terminal Type Blade
- Rated voltage DC UL 500 V
- ROHS Compliant Yes
- Mounting Bolted
- Connection/Terminal Material Silver-Plated Copper
- Speed/Characteristic Time Delay
- Fuse Class Class L
- Rated voltage AC UL 600 V
- AC Max I.R./Breaking Capacity: I1 200 kA
- Ampere Rating 2501 A
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
A4BQ2501 Description
A4BQ2501 Mersen - Fuse A4BQ - Class L - Time-Delay 600VAC 500VDC 2501A Blade Amp-Trap 2000®
