30305T Mersen Fuse Holders
Part#:30305T
Manufacturer:Mersen
Alt. Part#:782001675134
Product Lifecycle:Active
Get a quick Quote!
30305T Mersen - Fuse Block 300VAC 300VDC Class T 30A Adder Box with Reinforced Clip
About the manufacturer: Mersen is one of the manufacturers that offers Fuse Holders that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.
Check out the 30305T Mersen price in the box on the right side or send a quick quote.
Product Details
- Number of Poles Adder Pole
- Current Rating 30 A
- Weight 45.4 g
- Voltage 300 VAC
- Sell Pack Weight 0.53 lb
- Sell Pack Length 4.12 in
- Installation Mounting Direct Screw Mount
- Sell Pack Width 3.69 in
- Sell Pack Height 2.75 in
- Sell Pack Quantity 5 Each
- Product Length 3.37 in
- Product Height 1.47 in
- Product Width 3.6 in
- Max Fuse Rating 30 A
- Product Weight 0.1 lb
- Body/Insulating Material GFPC
- Fuse Installation Method Clip-in
- Fuse Type/Class Class T
- Rated voltage DC UL 300 V
- ROHS Compliant Yes
- Ampere Rating 30 A
- Short Circuit Current Rating (SCCR) 200
- Rated voltage AC UL 300 V
- Fuse Class Class T
- Number of Poles Adder
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
30305T Description
30305T Mersen - Fuse Block 300VAC 300VDC Class T 30A Adder Box with Reinforced Clip | Mersen Class T fuse blocks accommodate Class T fuses up to 600A. Insulators are either durable, glass-filled polycarbonate (GFPC) or phenolic with verified dielectric strength in excess of 2500V. Mersen is the only manufacturer to offer Class T blocks with copper connectors | Features: *Unique integral DIN-rail adapters for 600V, 30 & 60A blocks
*Full barrier design (30 & 60A) increases pole to pole safety
*Unique adder-block design (30 & 60A) for design flexibility
*Spring reinforcing standard for all 30 & 60A clips
*Features high conductivity copper alloy fuse clips
*Cool running high amperage (100 - 600A) connectors
*Copper connectors available 30 - 600A | Application:
Related documents 30305T Specs
