20315 Mersen Fuse Holders
Part#:20315
Manufacturer:Mersen
Alt. Part#:782001757526
Product Lifecycle:Active
Get a quick Quote!
20315 Mersen - Fuse Block 250VAC 250VDC Class H/K 30A Adder Screw with Reinforced Clip
About the manufacturer: Mersen is one of the manufacturers that offers Fuse Holders that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.
Check out the 20315 Mersen price in the box on the right side or send a quick quote.
Product Details
- Number of Poles Adder Pole
- Current Rating 30 A
- Weight 45.4 g
- Voltage 250 VAC
- Sell Pack Width 3.62 in
- Sell Pack Height 3.12 in
- Sell Pack Length 7.3 in
- Product Length 3 in
- Product Height 1.38 in
- Sell Pack Quantity 10 Each
- Product Width 0.91 in
- Product Weight 0.1 lb
- Installation Mounting Direct Screw Mount
- Max Fuse Rating 30 A
- Body/Insulating Material GFPC
- Fuse Installation Method Clip-in
- Rated voltage DC UL 250 V
- Number of Poles Adder
- Short Circuit Current Rating (SCCR) 50
- ROHS Compliant Yes
- Ampere Rating 30 A
- Fuse Type/Class Class H/K
- Rated voltage AC UL 250 V
- Fuse Class Class H/K
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
20315 Description
20315 Mersen - Fuse Block 250VAC 250VDC Class H/K 30A Adder Screw with Reinforced Clip | Mersen Class H, K and R fuse blocks accommodate all Class H, K and R 250 and 600V power fuses. A choice of screw, pressure plate, box and special order stud connectors fit a wide range of stranded or solid copper or aluminum wire. Insulators are either molded glass-filled polycarbonate (GFPC) or phenolic with verified dielectric strength in excess of 2500V. 30, 60 and 100A fuse blocks feature a unique adder block which can be snapped onto 1-, 2- or 3-pole blocks to form multipole segmented blocks of as many poles as desired.
All fuse clips are made of high conductivity tinplated copper, with a choice of spring reinforced or nonspring reinforced clips in 30A and 60A. Clips 100A and above are spring reinforced. | Features: | Application:
Related documents 20315 Specs
Manufacturer warranty
$23.60
