SK-750 Ilsco Industrial Automation Components

Ilsco SK-750 35 kV, 3/0 AWG to 750 KCMIL Stranded Run, 3/0 AWG to 750 KCMIL Stranded Tap, Silver, Electro Tin Plated High Strength Copper Alloy, Split Bolt Connector
Ilsco

Part#:SK-750

Manufacturer:Ilsco

Product Lifecycle:Active

Get a quick Quote!

35 kV, 3/0 AWG to 750 KCMIL Stranded Run, 3/0 AWG to 750 KCMIL Stranded Tap, Silver, Electro Tin Plated High Strength Copper Alloy, Split Bolt Connector

About the manufacturer: Ilsco is one of the manufacturers that offers Industrial Automation Components that you can order at Advantage Electric Supply site. ILSCO is a family-owned company that produces electrical connectors and accessories, with operations in three countries and a total of eight locations. The company employs over 1,000 individuals and representatives.

Check out the SK-750 Ilsco price in the box on the right side or send a quick quote.

Product Details

  • Series:
    SK
  • Minimum Tap Conductor Size:
    2/0 AWG Stranded
  • Volts:
    2000 V
  • Minimum Run Conductor Size:
    250 KCMIL
  • Maximum Tap Conductor Size:
    750 KCMIL
  • Maximum Run Conductor Size:
    750 KCMIL
  • Material:
    Electro-Tin Plated High Strength Copper Alloy
  • Conductor Material:
    Copper
  • Shipping Weight:
    1.90 lbs.
  • Shipping Width:
    5.00 In.
  • Installation:
    Split Bolt with Spacer Bar
  • Approval:
    UL 460C
  • Shipping Length:
    6.00 In.
  • Shipping Height:
    3.00 In.
  • UPC:
    78366981915

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents SK-750 Specs

SK-750 CADDrawing.pdf
SK-750 SpecificationTechnical.pdf
