IG5715 ifm Electronic Electronic Components
![ifm Electronic IG5715 Inductive sensor, Robust metal housing for use in harsh industrial environments, Electrical design: PNP/NPN, Output function: normally open, Sensing range [mm]: 8, Housing: Threaded type, Dimensions [mm]: M18 x 1](/_next/image?url=https%3A%2F%2Fappstoragepublicprod.s3.us-west-1.amazonaws.com%2FPartImage%2F474ce4cc-95bf-4980-94e3-61d8a39b18c8.jpg&w=3840&q=75 "ifm Electronic IG5715 Inductive sensor, Robust metal housing for use in harsh industrial environments, Electrical design: PNP/NPN, Output function: normally open, Sensing range [mm]: 8, Housing: Threaded type, Dimensions [mm]: M18 x 1")
Part#:IG5715
Manufacturer:ifm Electronic
Product Lifecycle:Active
Get a quick Quote!
Inductive sensor, Robust metal housing for use in harsh industrial environments, Electrical design: PNP/NPN, Output function: normally open, Sensing range [mm]: 8, Housing: Threaded type, Dimensions [mm]: M18 x 1
About the manufacturer: ifm Electronic is one of the manufacturers that offers Electronic Components that you can order at Advantage Electric Supply site. Through years of working closely with our customers, we have established ourselves as experts in sensor technology, dedicated to delivering outstanding service. Currently, our company operates in more than 85 countries and employs a team of over 7,000 individuals. Despite our expansion, our dedication to customer satisfaction remains unwavering.
Check out the IG5715 ifm Electronic price in the box on the right side or send a quick quote.
Product Details
- Switching frequency DC [Hz] 300
- Overload protection yes
- Short-circuit protection yes
- Type of short-circuit protection yes (non-latching)
- Permanent current rating of switching output DC [mA] 150
- Max. leakage current [mA] 0.8
- Max. voltage drop switching output DC [V] 4.6
- Minimum load current [mA] 4
- Reverse polarity protection yes
- Output function normally open
- Operating voltage [V] 10...36 DC
- Dimensions [mm] M18 x 1
- Protection class II
- Sensing range [mm] 8
- Electrical design PNP/NPN
- Housing Threaded type
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
Related documents IG5715 Specs
