FAZ-K0.5/4 Eaton Electronic Components

Name: FAZ-K0.5/4
Brand: Eaton

Part#:FAZ-K0.5/4

Manufacturer:Eaton

Product Lifecycle:Active

Get a quick Quote!

Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,0.5 A,15 kAIC,Four-pole,8-12X /n,Standard terminals,K curve

About the manufacturer: Eaton is one of the manufacturers that offers Electronic Components that you can order at Advantage Electric Supply site. At Eaton, we are dedicated to improving quality of life and preserving the environment through power management technologies that emphasize reliability, efficiency, safety, and sustainability. Our attention is on impactful solutions, and we are committed to their success.

Check out the FAZ-K0.5/4 Eaton price in the box on the right side or send a quick quote.

Product Details

Number of Poles
4 Pole
Current Rating
0.5 A
Trip Curve
K
SCCR
5 kA
UL Standard
1077
UL CCN
QVNU2
UL File No.
E177451
Terminal Type
Compression
Trip Type
8-12X /n
Terminals
Standard
Number of poles
Four-pole
Amperage Rating
0.5 A
Catalog Notes
Applications suited for highly inductive loads. Similar to D but with a more narrow range.
Product Width
3 in
Certifications
IEC 60947-2 UL 1077 CSA Std. C22.2 No.235
Warranty
1 year
Product Length/Depth
3 in
Product Weight
1 lb
Catalog Number
FAZ-K0.5/4
EAN
4015082790899

Product Height

3 in

Product Name

Eaton FAZ supplementary protector

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
