FAZ-D13/1N Eaton Electronic Components
Part#:FAZ-D13/1N
Manufacturer:Eaton
Product Lifecycle:Active
Get a quick Quote!
Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,High levels of inrush current are expected,13 A,15 kAIC,Single-pole,240 V,10-20X /n,50-60 Hz,Standard terminals,D Curve
About the manufacturer: Eaton is one of the manufacturers that offers Electronic Components that you can order at Advantage Electric Supply site. At Eaton, we are dedicated to improving quality of life and preserving the environment through power management technologies that emphasize reliability, efficiency, safety, and sustainability. Our attention is on impactful solutions, and we are committed to their success.
Check out the FAZ-D13/1N Eaton price in the box on the right side or send a quick quote.
Product Details
- Number of Poles 1 Pole
- Current Rating 13 A
- Trip Curve D
- SCCR 5 kA
- UL Standard 1077
- UL CCN QVNU2
- UL File No. E177451
- Terminal Type Compression
- Amperage Rating 13 A
- Number of poles Single-pole
- Terminals Standard
- Trip Type 10-20X /n
- Catalog Notes Magnetic range for higher startup inrush levels that are usually seen in motors and transformers, and other high inductive systems.
- Warranty 1 year
- Certifications IEC 60947-2 UL 1077 CSA Std. C22.2 No.235
- Product Height 1.5 in
- Product Weight .5 lb
- Product Width 3 in
- Product Length/Depth 1.5 in
- Catalog Number FAZ-D13/1N
- EAN 4015082786953
- Product Name Eaton FAZ supplementary protector
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
Related documents FAZ-D13/1N Specs
