FAZ-D1/3N Eaton Miniature Circuit Breakers (MCBs)

Eaton FAZ-D1/3N UL 1077 Industrial Miniature Circuit Breaker - Supplementary Protector

Eaton

Part#:FAZ-D1/3N

Manufacturer:Eaton

Product Lifecycle:Active

Get a quick Quote!

UL 1077 Industrial Miniature Circuit Breaker - Supplementary Protector

About the manufacturer: Eaton is one of the manufacturers that offers Miniature Circuit Breakers (MCBs) that you can order at Advantage Electric Supply site. At Eaton, we are dedicated to improving quality of life and preserving the environment through power management technologies that emphasize reliability, efficiency, safety, and sustainability. Our attention is on impactful solutions, and we are committed to their success.

Check out the FAZ-D1/3N Eaton price in the box on the right side or send a quick quote.

Product Details

UL CCN
QVNU2
UL File No.
E177451
Terminal Type
Compression
Trip Curve
D
Current Rating
1 A
Number of Poles
3 Pole
UL Standard
1077
SCCR
5 kA
Number of poles
Three-pole + N
Amperage Rating
1 A
Trip Type
10-20X /n
Application
Suitable for applications where high levels of inrush current are expected
Frequency rating
50-60 Hz
Type
UL 1077 Industrial miniature circuit breaker - supplementary protector
Terminals
Standard
Circuit protection
D curve
Interrupt rating
15 kAIC
Catalog Notes
Magnetic range for higher startup inrush levels that are usually seen in motors and transformers, and other high inductive systems.
Product Width
3 in
Product Weight
1 lb

Certifications

IEC 60947-2 CSA Std. C22.2 No.235 UL 1077

Warranty

1 year

Product Height

3.25 in

Product Length/Depth

2.76 in

EAN

4015082789831

Catalog Number

FAZ-D1/3N

Product Name

Eaton FAZ supplementary protector

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
