FAZ-C10/1N Eaton Miniature Circuit Breakers (MCBs)
Part#:FAZ-C10/1N
Manufacturer:Eaton
Product Lifecycle:Active
Get a quick Quote!
Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,Medium levels of inrush current are expected,10 A,15 kAIC,Single-pole,240 V,5-10X /n,50-60 Hz,Standard terminals,C Curve
About the manufacturer: Eaton is one of the manufacturers that offers Miniature Circuit Breakers (MCBs) that you can order at Advantage Electric Supply site. At Eaton, we are dedicated to improving quality of life and preserving the environment through power management technologies that emphasize reliability, efficiency, safety, and sustainability. Our attention is on impactful solutions, and we are committed to their success.
Check out the FAZ-C10/1N Eaton price in the box on the right side or send a quick quote.
Product Details
- Number of Poles 1 Pole
- Current Rating 10 A
- Trip Curve C
- SCCR 10 kA
- UL Standard 1077
- UL CCN QVNU2
- UL File No. E177451
- Terminal Type Compression
- Interrupting Rating: 10 kA
- Wire Size: 18 to 4/18 to 8 AWG
- Mounting: DIN Rail
- Amps: 32 A
- Poles: 1+N
- Trip Setting: 5 to 10 x Rated Current
- Terminal Type: Line/Load
- Type: Current Limiting
- Volts: 277/480 VAC
- Size: 0.7 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Series: FAZ
- Approval: UL 1077
- Shipping Weight: 0.45
- Shipping Width: 4.00 In.
- Shipping Length: 3.00 In.
- Shipping Height: 2.00 In.
- Trip Type 5-10X /n
- Number of poles Single-pole
- Amperage Rating 10 A
- Voltage rating 240 V - 240 V
- Terminals Standard
- Circuit protection C curve
- Application Suitable for applications where medium levels of inrush current are expected
- Frequency rating 50-60 Hz
- Type UL 1077 Industrial miniature circuit breaker - supplementary protector
- Interrupt rating 15 kAIC
- Catalog Notes Positioned for medium inrush startup currents to provide protection for small transformers and pilot devices.
- Certifications UL 1077 CSA Std. C22.2 No.235 IEC 60947-2
- Catalog Number FAZ-C10/1N
- Warranty 1 year
- Product Weight .45 lb
- Product Length/Depth 1.38 in
- Product Height 1.38 in
- Product Width 3 in
- Product Name Eaton FAZ supplementary protector
- EAN 4015082786700
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
Related documents FAZ-C10/1N Specs
