AM1206HP16 Allied Moulded Products Pushbutton Enclosures
Part#:AM1206HP16
Manufacturer:Allied Moulded Products
Product Lifecycle:Active
Get a quick Quote!
12"x10"x6" AM Series fiberglass wall mount enclosure assembly with 2-screw hinged cover and 16 pushbutton holes
About the manufacturer: Allied Moulded Products is one of the manufacturers that offers Pushbutton Enclosures that you can order at Advantage Electric Supply site. Allied Moulded offers a wide range of products for residential and manufactured housing, including fiberglass range/dryer receptacle boxes, floor boxes, lampholders, luminaires, and more. These products are designed to meet the needs of both electrical professionals and DIY enthusiasts.
Check out the AM1206HP16 Allied Moulded Products price in the box on the right side or send a quick quote.
Product Details
- UL Standard 508A
- UL CCN NITW
- UL File No. E120175
- Width 10.26 in
- Height 12.14 in
- Depth 6.01 in
- NEMA Rating 4X
- Material Fiberglass
- Color Gray
- Type Wallmount
- Door Qty 1
- UPC: 85339912187
- Application: Designed to protect push-button switches from damage and wear, these enclosures have holes for mounting push buttons and an internal compartment to house associated wires and mechanisms. Push buttons are often used for operating industrial machines or pro
- Carton Quantity: 1
- Features: Non-corrosive, non-conductive, light weight with lower installation cost, easy to modify and longer life cycle compared to steel. Rigid design with back panel inserts plus stainless steel mounting brackets and a gasket system encased in a continuous chann
- Color: Gray (RAL 7035)
- Material: ULTRAGUARD® Fiberglass reinforced polyester - compression molded SMC box and Cover
- Additional Materials: 316 stainless steel external hardware (hinges/latches/fasteners), 316 stainless steel mounting brackets, Plated carbon steel internal hardware, Brass inserts, Polyurethane (FIP) Formed-In-Place gasket system
- UNSPSC: 39121326
- Usable Depth: 5.68 in
- Country of Origin: United States of America
- Standards: UL 508A, UL 50 and UL 50E Types 1, 2, 3, 3R, 4, 4X, 12 and 13; File No. E120175Complies with: 1. EN / IEC 60204-1 and 60529 Type IP66 2. RoHS directive
- Volume: 764 cu. in.
- Carton Weight: 7 lbs
- Brand: AM Series
- Depth: 6.01 in
- Height: 12.14 in
- Cover Type: Opaque
- Width: 10.26 in
- Mounting Description: Stainless steel feet fastened to back side brass inserts
- Enclosure Type: Pushbutton
- Closure Type: 2-Screw
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
Related documents AM1206HP16 Specs
