FAZ-C16/3 Eaton Miniature Circuit Breakers (MCBs)
Part#:FAZ-C16/3
Manufacturer:Eaton
Product Lifecycle:Active
Get a quick Quote!
UL 1077 Industrial Miniature Circuit Breaker - Supplementary Protector
About the manufacturer: Eaton is one of the manufacturers that offers Miniature Circuit Breakers (MCBs) that you can order at Advantage Electric Supply site. At Eaton, we are dedicated to improving quality of life and preserving the environment through power management technologies that emphasize reliability, efficiency, safety, and sustainability. Our attention is on impactful solutions, and we are committed to their success.
Check out the FAZ-C16/3 Eaton price in the box on the right side or send a quick quote.
Product Details
- Number of Poles 3 Pole
- Current Rating 16 A
- Trip Curve C
- SCCR 10 kA
- UL Standard 1077
- UL CCN QVNU2
- UL File No. E177451
- Terminal Type Compression
- Number of Poles 3
- Amperage 16 amperes
- Terminal Type Standard Terminals
- Number of poles Three-pole
- Circuit protection C curve
- Amperage Rating 16 A
- Trip Type 5-10X /n
- Terminals Standard
- Application Suitable for applications where medium levels of inrush current are expected
- Frequency rating 50-60 Hz
- Type UL 1077 Industrial miniature circuit breaker - supplementary protector
- Catalog Notes Positioned for medium inrush startup currents to provide protection for small transformers and pilot devices.
- Interrupt rating 15 kAIC
- Product Weight .8 lb
- Product Height 2.07 in
- Certifications CSA Std. C22.2 No.235 UL 1077 IEC 60947-2
- Product Width 2 in
- Warranty 1 year
- EAN 4015082788735
- Product Length/Depth 2.07 in
- Catalog Number FAZ-C16/3
- Product Name Eaton FAZ supplementary protector
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
Related documents FAZ-C16/3 Specs
